Hitting the roads today with tomorrow's safety in mind. This specially engineered rehabilitation car seat not only meets current safety standards but is also designed to comply with future regulations effective from September 2023. The Hercules Small, tested according to the latest R129 standard, which includes both frontal and side impact considerations, provides a high level of safety and effective protection for your child.
Features
Backrest Height
The backrest can be continuously adjusted in height by 24 cm, allowing it to accommodate the child's growth over time.
Leg Guide
Users, whether narrow or wide, with seat widths ranging from 29 to 38 cm, are well-supported at all times.
Side Impact Protectors
The side impact protectors offer exceptional side impact protection, effectively absorbing forces, particularly in the head and shoulder areas.
Compact and Convenient
With a few simple movements, the new Hercules Small rehab car seat folds into a slim, easy-to-handle format..
Hercules Small: Swivel and Tilt Functionality
Swivel Function
The Hercules Small features a swivel function, allowing the seat to be turned toward the passenger side vehicle door. This makes entry and exit from the booster seat much more convenient. Simply press the red trigger and rotate the seat toward the open vehicle door.
Tilt Function
The tilt function aids in positioning the child optimally, especially if upper body or head control is limited. The Hercules Small can be tilted backward in 2.5° increments, up to a maximum of 10°.
Choice of Colors
The Hercules Small goes beyond basic features, offering critical enhancements such as side impact protection, pelvic guidance, leg guidance, and head support. These elements not only meet strict safety standards but also ensure the child's comfort and support. Safety has never been so comfortable!
Grey/Blue
Grey/Red
Headrest
The headrest is asynchronously adjustable in both width and height. With additional accessories, it can also be adjusted in depth to prevent stimulus overload.
Adjustable Back Angle
The back angle can be continuously adjusted using two quick handles, without the need for any tools. Simply use the red quick-release clamps for easy adjustment.
Belt Buckle & Shield Pad
The shoulder straps can be individually clicked into the quick-release buckle, making it easier for parents or companions to buckle up the child.
Adjustable Seat Depth
The seat depth can be infinitely adjusted by 6 cm, allowing for individual adaptation as the child grows.
Exploring Hercules Prime Booster
A robust solution is essential for children, young people, and adults with physical and neurological disabilities to ensure their safety in the car. Hercules Prime US excels when adapted car seats become too small or when additional support is needed while sitting in the car. This positioning booster seat grows with the user, offering the familiar features of an adapted car seat and can be highly customized with a wide range of accessories that adapt as the user grows. When extra head and upper body support is required, a basic seatbelt system in the car is insufficient. This seat ensures a proper, safe sitting position on every journey.
Size Chart
| Dimensions and Weights | Hercules Small |
|---|---|
| User Weight | 40 - 110 lbs |
| Weight of Seat | 25.6 lbs |
| Seat Depth | 12.2" - 16.5" |
| Depth Behind Crotch Strap | 7.9" - 13" |
| Seat Width | 11.4" - 15" |
| Seat to Head | 22.4" - 31.5" |
| Back Width (Seat) | 17.7" |
| Shoulder Height | 14.2" - 23.6" |
| Shoulder Width | 17.7" |
| Shoulder Width with Shoulder Pad | 14.6" |
| Back Angle (Max.) | 90° - 145° |
| Seat Tilt-in-Space (With Tilting Base 10°) | 0° / 2.5° / 5° / 7.5° / 10° |
| Lower Leg Length (With Foot Rest) | 6.3" - 16.5" |
| Height of Lateral Trunk Supports (Upper Edge) | 11" - 13.4" |
| Distance Lateral Supports | 7.9" - 13" |
| Max. Overall Dimensions (w x h x d) | 21.7" x 33.5" x 13.4" |
| Min. Folded Dimensions (w x h x d) | 21.7" x 9.1" x 23.6" |
| Body Size User | 43.4" - 59" |
Accessories & Options
Lower Anchor
Keeps the seat securely in place while swiveling.
Stabilizing Bow
Provides a more stable position while swiveling when the vehicle lacks a Latch system.
Second Belt Guide (Top)
Offers a convenient option for using the 3-point safety belt on either the right or left side.
Footrest (Foldable)
Eases getting in and out, prevents slipping out of the seat, and allows for height and angle adjustments.
Front Stand
Ensures the booster seat remains stable when getting the child in and out of the vehicle, with adjustable height and angle..
Lateral Trunk Support (Firm)
Offers firm lateral support and chest support
Lateral Trunk Support (Swing-Away)
Offers firm lateral support for the chest and aids in transfers
Shoulder Pads
Reduces shoulder width by approximately 3.1 inches
Additional Extension (Head Area height)
Offers a larger area for the child's head to rest against.
Armrests
offers excellent support for the forearms
Table
Promotes the child's upright posture and provides additional safety (can only be used with armrests).
Head Additional Cushion
Offers an even softer contact surface for the head. The filling in the center and both sides is removable.
Abduction Block
Enhances leg control and prevents the legs from crossing.
Belt Guide
Provides intuitive and safe harnessing with the 3-point harness, eliminating the need for threading through or twisting.
Cushion for Functional Base
Ensures maximum support surface between the vehicle seat and the functional base, facilitating easier transfer.
Front Cover
Offers a soft surface when wearing shorts or skirts.
Incontinence Pad
The incontinence seat pad is placed on the seat cushion to protect the upholstery. It is easy to remove for quick cleaning.
